It can withstand even extreme loads in any position. The structure enables it to be adapted to match the size of the patient and in no time at all it can be equipped for any surgical discipline. A longitudinal shift of up 350mm makes the operating table even more versatile.
Engineered for increasingly complex surgical scenes, It comes with intelligent automatic control system satisfying various demands of general surgeries. Extra wide tabletop, extreme loading system, long horizontal sliding that can be suitable for both X-ray and C-arm. It is an ideal electric operating table.
• Longitudinal slide up to 350mm for free access to C arm
• Extreme weight load capacity of 250kgs with highest safety and stability
• Memory pad with antistatic,waterproof design
• Standard override panel control makes the control safer
• Battery power for 50-80 operations
Length | Width | Tabletop lowest height | Elevation range |
≥2100mm | 550mm | ≤700mm | 300mm |
Parameter
Movements | ||
Tabletop trendelenburg | Reverse Trendelenburg | ≥25° |
Trendelenburg | ≥25° | |
Lateral Tilt (Left And Right) | ≥15° | |
Head plate | Up | ≥45° |
Down | ≥90° | |
Flexible | ≥40° | |
Back plate | Up | ≥80° |
Down | ≥20° | |
Leg plate | Up | ≥15° |
Down | ≥90° | |
Outward | ≥90° | |
Kidney Bridge Elevation | ≥120mm | |
Horizontal Sliding Range | ≥350mm | |
Disposition
Anaesthesia screen | 1 piece | Shoulder support (cushion） | 2 piece | Arm support（cushion） | 2 piece |
Body support（cushion） | 2 piece | Leg support（cushion） | 2 piece | Foot plate（cushion） | 2 piece |
Long Fixing Clamp | 2 piece | Fixing Clamp | 7 piece | Controller | 1 piece |
Hand-held operator | 1 piece | Mattress | 1 piece | Power line | 1 piece |
